Gantry Planetary Mixer: LV Series

During the operation of the LMT series power vacuum mixer, the two parallel stirring paddles operate according to a set fixed rotation ratio. While revolving along the mixing barrel, they also rotate rapidly, allowing the material to move from the inner wall of the mixing barrel to the vicinity of the mixing paddle. The high-speed dispersing toothed discs of the other two separate power units also rotate along the mixing barrel with the revolution to perform efficient dispersion and emulsification. Both the stirring paddles and the high-speed dispersing toothed discs are frequency-controlled, and the speed can be customized according to the production process to achieve different results. Cutting purpose. This type of movement can achieve a completely uniform mixing effect of materials in a short period of time.


This series is designed for mass production. The volume of the barrels ranges from 350L to 1500L to meet different mass production needs.

Product Advantages
Material Selection
Technical Parameters
Applications

Product Advantages of Gantry Planetary Mixer: LV Series


  • Sun gears and planetary gears are carburized and quenched with high-quality alloy steel, the ring gear is surface-hardened with high-quality alloy steel, and all gears are processed by grinding;

  • The planet carrier and the bearing seat are welded with cast steel or high carbon steel and annealed to eliminate stress. The box body and the planet carrier are optimized by means of computer simulation deformation and stress analysis, so that the bearing capacity is higher;

  • Highly modular the design can standardize many basic parts, which is more economical in mass production, effectively reduces the amount of inventory and improves the speed of delivery;

  • All bearings adopt roller bearings with appropriate specifications, and the bearings of the stressed parts are all imported brands;

  • Both the planetary shaft and the dispersed shaft adopt radial skeleton oil seals, and the radially loaded shaft adopts double sleeve pressure-resistant oil seals;

  • It comes with a wealth of accessories for customers to choose, and can be combined with other products of our company to form a production line system with more functions.


Material Selection of Gantry Planetary Mixer: LV Series


Material Selection of Gantry Planetary Mixer: LV Series




Technical Parameters of Gantry Planetary Mixer: LV Series

Technical Parameters of Gantry Planetary Mixer: LV Series
